Ø 45
E: Electronic Limit + Build in Receiver
Smart Solutions with Integrated Receiver!
Easy to install with its built-in receiver feature and can be used in awnings,blinds and roller shutter systems. With its low-noise operation technology and energy-saving features, this motor provides reliable performance and long-lasting use. Its modern design and integrated features allow users to take full control of their homes or workplaces.
User Manual
Technical Specifications
| MOTOR TYPE | OPERATING VOLTAGE | RATED TORQUE | RATED SPEED | TUBE DIAMETER | RATED POWER INPUT | RATED CURRENT | OPERATING TIME | MAX. NUMBER OF TURNS | WEIGHT | IP PROTECTION |
|---|---|---|---|---|---|---|---|---|---|---|
| 45E-50/12 | 230V/50 Hz | 50 N.m | 12 rpm | 45 mm | 230W | 1.02 A | 4 min. | ∞ Turns | 2.77 kg | IP44 |
| 45EP-50/12 | 230V/50 Hz | 50 N.m | 12 rpm | 45 mm | 230W | 1.02 A | 4 min. | ∞ Turns | 2.77 kg | IP55 |
